Sun tracking system 600w-2FSA013

This product is a solar power supply system designed by plant bionics, which integrates solar power generation, energy storage, inverter and control. It can be used in scenic spots, schools, parks, villages and other places to supply power for digital products such as electric bicycles and mobile phones. In addition to the safety, reliability, long life, no energy consumption and no pollution


Keywords

Emergency Battery Backup

Portable solar power for household

Solar charge portable unit

Super charge portable solar panel



  • Product Features
  • Technical parameters
  • This product is a solar power supply system designed by plant bionics, which integrates solar power generation, energy storage, inverter and control. It can be used in scenic spots, schools, parks, villages and other places to supply power for digital products such as electric bicycles and mobile phones. In addition to the safety, reliability, long life, no energy consumption and no pollution, this product has the following characteristics:

    1, novel shape and beautiful appearance.

    2, high power generation efficiency.

    3. Small site occupation.

    4, easy to install.

    5, can be connected to the grid expansion.



    Application









  • product model 2FSA009
    solar panel total power 800W
    battery capacity 48V/ 100Ah
    battery type POZV
    inverter output 2000 VA,AC 230V / 50Hz
    DC Output DC5V/3A, QC3.0 2pcs
    Control Type Vertical Single Axis, learning time control
    pitch angle range 0, 15, 25, 35, 45, 55
    tracking power consumption ≤ 10 Wh/day Day
    total weight 300Kg
    total product height 3.9m
    (45 inclination inclination)
    disc diameter 2.57m (max)
    working temperature -40 ℃ ~ 55 ℃
    protection grade IP24
    salt fog can withstand salt Spray Corrosion in Coastal Areas

    Solar Auto Tracking
